PRONTO ACCESS EQUIPMENT

New LGMG 26ft Narrow Electric Scissor Lift
Measurements
Work Height Max. 9.8/8m (in/out)
Platform Height-Raised 7.8/6m(in/out)
Platform Length 2.26m
Platform Width 0.79m
Overall Length 2.44m
Overall Width 0.83m
Overall Height-Guardrails Up 2.28m
Overall Height-Guardrails Down 1.9m
Extension Deck 0.9m
Wheelbase 1.85m
Ground Clearance (Stowed/Raised) 100/20mm
Productivity
Max. Platform Occupants (In/out) 2 (in) /1 (out)
Platform Capacity 230kg
Platform Capacity-Extension Deck 120kg
Drive Height Full Height
Gradeability-Stowed 25%
Min. Turning Radius 2.2m
Raise/Lower Speed 31s /40s
Brakes Front-wheel Brake
Drive Mode 4×2
Tire Type Solid Non-marking
Tire Size 380*130mm
Power Source 24V 225Ah
Hydraulic Oil Capacity 13L
Machine Weight 2200kg
The second generation of scissors lifts has been improved in various aspects, such as performance and design, which makes them even more convenient to maintain and safer to operate.
Large lower control panel
Entire range designed for indoor and outdoor use
Universal key components
More convenient to maintain
Optional lithium battery for the entire product range

LGMG S0808EII

UP LIFT UG30AC

UP LIFT UG35AC

New Galvanised Scissor Lift Trailer
Suits all manufacturers 19ft electric scissor lifts
ATM 2,600kg
Tare 430kg
Carrying capacity 2,170kg
Rear Loading Ramps
Dual axles
Alko independent rubber suspension
Mechanical Drum brakes on both axles
New tyres
LED Lights
Side clearance light
Heavy Duty jockey wheel
Spare wheel
No electric brakes required
5-year chassis warranty
FEEL FREE TO CALL PRONTO ACCESS FOR ALL INFORMATION CONCERNING THIS MACHINE AND ANY OTHER PRODUCT WE SELL

BRIAN JAMES ECO 2

LGMG S1212EII

JLG NON-POWERED VERTICAL LIFT ECO Lift 70

JLG ECO LIFT 70

The Snorkel S3013 MINI scissor lift is mighty. Its small enough to pass through a standard doorway, yet mighty enough to provide all day versatility for any sized job. Easy to use, efficient, and reliable, the compact S3013 MINI is a perfect choice for any indoor construction or maintenance application
- Full electric drive micro scissor
- 2 person Indoor / 1 person outdoor rated 100% operation
- Fixed control box with pendant controller
- Total machine weight 794kgs
- 272kgs platform capacity
5 year warranty on lithium batteries
Max Working Height 6m
Max. Platform Height 4m
Platform Size (stowed) 0.75m x 1.32m
Platform Size (extended) 0.75m x 1.93m
Deck extension length 0.61m
Overall length (with step) 1.44m
Overall length (without step) 1.39m
Overall Width 0.76m
Min. Height (guardrails folded) 1.59m
Stowed Height 1.85m
Platform Capacity (SWL) 272kg
Max Drive Height 5.79m
Max Drive Speed (stowed) 4.0km/h
Max Drive Speed (elevated) 0.8km/h
Raise/Lower Time 20/35 seconds
Gradeability 25%
Inside Turning Radius 0.13m
Outside Turning Radius - 1.47m
Controls - Proportional
Drive System 2 wheel electric drive
Power Source Lithium Batteries
Weight 794kg

SNORKEL S3013 MINI

6m 2.5Ton Telehandler - Telescopic Material Handler 4WD - New

LGMG H625

10-year Recertified JLG 260 MRT 26ft Diesel 4WD Rough Terrain Scissor Lift
Into service in 2014
Low 1228 hours
Recertified in 2025 by JLG
Full Respray
4 x New solid non marking all terrain tyres
4WD all terrain diesel scissor lift
Kubota diesel motor 24hp/18kw
Max platform height 8 metres
Max Working height 10 metres
Safe working load 565kgs
2 speed
Extendable platform
Ground & Basket controls
E-stops
The machine has 4 x hydraulic Outriggers that can be self-levelled
Lift and Tie down points
Smooth control, proportional drive, with two speed ranges
Kubota D1005 diesel engine with increased HP output
Fold down rails allows drive through a 203cm door
Extension platform has fold down rails.
Urethane filled non-marking lug tyres
Steering with tight 213cm turning radius
Constant traction 4 wheel drive for 35 per cent gradeability
Wide scissor stack provides rigidity and stability
Extended stabilisers prevent drive.
Auto level stabiliser feature allows adjust lateral stabiliser levelling from steer switch
Multi axis 4 degree level sensor
Plug in JLG analyser to indicate system functions for servicing and adjustment
Removable platform control box

JLG 260MRT

USED GENIE 32FT NARROW ELECTRIC SCISSOR LIFT

Into Service 2011

Was recertified in 2021  just come out of time

Hours - 321

	Machine in fair condition

Machine Specifications:
 11.75 m (38 ft) working height
 Up to 227 kg lift capacity
